SEQUEL
URBAN ADVENTURE BIKES
Manufacturer’s Suggested Retail Price excludes shipping costs, dealer assembly/prep, taxes or import duties.
FRAME DESIGN
Starting with a wide and consistent stack and reach range, we set out to design a frame that could handle your everyday city life. Whether you’re commuting year-round in mother nature’s worst conditions or hitting up a dirt trail after work the Sequel will make it happen and maintain a comfortable ride. Depending on size, Sequel offers 2 different fork offsets, 3 different BB drops and multiple rear center measurements. Add size-specific tubing and you’ve got the perfect fit for all sized riders. This level of customization allows the best fit and the most comfort possible.
SIZE SPECIFIC DESIGN
Size Specific Design (SSD) is the Jamis design philosophy and technique used to create the best possible riding bike for riders of all sizes. Rather than limiting frame size variations to just different length top, seat, and head tubes, we take an all-inclusive look at each frame’s total configuration. Every SSD frame will also feature size-specific BB drop, rear center, fork offset/trail and size-specific tubing technology.
12MM THRU-AXLE
Securing the wheel to the frame and fork by threading it into the rear dropouts is not only safer, it’s stiffer. Increasing the axle diameter from 10mm to 12mm provides a stable platform for the disc brake forces and allows us to tune the fork and rear seat stays for more compliance/comfort. You will appreciate this on every ride.
DISC BRAKES
The Sequel is designed for anything your daily commuting life can throw at you, so hydraulic disc brake is the only choice. These brakes provide the most consistent and confidence-inspiring braking available. Just think about jamming down Park Avenue between cars in the rain…the power & modulation benefits of hydraulic disc brakes become readily apparent.
DROPPER POST READY
Just in case you want to continue to push the boundaries, we added external cable routing capability for a 27.2mm dropper post on both Sequel models.
MORE MOUNTS
To make life easier we have repositioned each mount externally in a variety of easy-to-use locations. With a wide collection of fork and frame mounts you can now choose to mount fenders, rear carrier, low-rider front carrier (or two cages for water bottles/ storage), top tube bags, and three water bottles in the front triangle. This opens up the options wherever and whenever you choose to ride. Bad weather, commuting, a short ride to the park or a longer adventure – anything is possible.
TUBELESS MTB RIMS
Tubeless and wide rims on both models provide great benefits on all types of terrain. Tubeless not only helps prevent flats with sealant, but also allows a wider range of tire pressure adjustment. Reduce the tire pressure on dirt trails to increase your contact patch for better grip without the worry of pinch flatting. 23mm internal width rims help provide a consistent and wide tire surface yielding better handling, stability and confidence with plenty of surface grip for control.
ROAD PLUS TIRES
Road Plus 47c tires bring supple traction and smooth riding characteristics to the pavement and beyond. The WTB Byway tire pairs a smooth centerline with various levels of outer tread/knobs, providing different degrees of resilience and cornering traction to suit specific uses. High-volume tires provide performance on pavement in the urban jungle with resiliency that isn’t shaken by chasing your buddies down rail trails or dirt roads. Ride it on tarmac, take it to the dirt as well. Sequel creates a new riding experience, regardless of where your exploits lead you.
THE URBAN RENEGADE
Think of the Sequel as an urban Renegade, built to tackle anything midtown can throw at it. Our SSD custom geometry and Reynolds double-butted chromoly frame deliver a comfortable ride with maximum stability in every frame size. While those 650b wheels offer both the security of 12mm thru-axle mounting and the pot-hole-eating capability of high-volume 47c tires. Toss in high-powered hydraulic disc brakes, a no-nonsense 1 x 10 drivetrain and a ton of fender, bottle and rack mounts and the Sequel is clearly ready for urban assault no matter the surface or condition.
SEQUEL S2
MSRP: $1299.95
Purchase online now and pickup at your local bike shop!
- Jamis Size Specific Design, Reynolds 520 double-butted chromoly frame
- Jamis Chromoly fork, 12mm thru-axle dropouts
- WTB ST i25 TCS 2.0 (UST Tubeless Compliant System) disc rims
- WTB Byway Tire with DNA compound
- Shimano Deore RapidFire Plus SL, 10-speed
- Shimano Deore RD-M4120 GS Shadow Plus rear
- FSA Vero Pro crankset
- Tektro HD-M280/281 hydraulic Flat Mount disc brakes
- Selle Royal Vivo ERGO saddle
FRAME DESIGN
Starting with a wide and consistent stack and reach range, we set out to design a frame that could handle your everyday city life. Commuting year round in mother nature’s worst conditions or hitting up a dirt trail the Sequel will make it happen and maintain a comfortable ride. As you start to review the geo chart you’ll noticed we have 2 different fork offsets, 3 different BB drops and rear center measurements. Add size specific tubing and you have what we feel is the perfect fit for all sized riders. The reason for this custom geometry is to give you the best fit and the most comfort possible.
MORE MOUNTS
To make life easier we have positioned each mount externally in a variety of easy-to-use locations. With a wide collection of fork and frame mounts you can now choose to mount fenders, rear carrier, low-rider front carrier (or two cages for water bottles/ storage) and three front triangle water bottles. This will open up the options wherever and whenever you chose to ride. Bad weather, commuting, a short ride to the park or a longer adventure – anything is possible.
SEQUEL S3
MSRP: $1099.95
Purchase online now and pickup at your local bike shop!
- Jamis Size Specific Design, 4130 double-butted chromoly main tubes
- Jamis Chromoly fork, 12mm thru-axle dropouts
- WTB ST i25 TCS 2.0 (UST Tubeless Compliant System) disc rims
- WTB Byway Tire with DNA compound
- Shimano Altus RapidFire Plus, 9-speed
- FSA Tempo crankset
- Tektro HD-M280/281 hydraulic Flat Mount disc brakes
- Jamis Sport saddle with SL top
Specifications are subject to change without notice. All bike and frame weights are based off pre-production painted frames. Weights may vary in final production.
| SEQUEL | S2 | S3 |
|---|---|---|
| Frame | Jamis Size Specific Design frame geometry, Reynolds 520 double-butted chromoly main tubes, threaded BB shell, chain stay flat mount disc brake mounts, 12mm thru-axle, FD mount, dropper post ready, 3 waterbottle mounts, TT mounts, rack and fender eyelets, 29.8mm seatpost clamp | Jamis Size Specific Design frame geometry, 4130 double- butted chromoly main tubes, threaded BB shell, chain stay flat mount disc brake mounts, 12mm thru-axle, FD mount, dropper post ready, 3 waterbottle mounts, TT mounts, rack and fender eyelets, 29.8mm seatpost clamp |
| Fork | Jamis Chromoly fork, 12mm thru-axle dropouts, 45mm crown, flat mount disc brakes, fender, lowrider and water bottle eyelets | Jamis Chromoly fork, 12mm thru-axle dropouts, 45mm crown, flat mount disc brakes, fender, lowrider and water bottle eyelets |
| Headset | FSA IS3 Internal headset 1 1/8” | FSA IS3 Internal headset 1 1/8” |
| Wheels | WTB ST i25 TCS 2.0 (UST Tubeless Compliant System) disc rims, 32H, Formula alloy 6-bolt sealed bearing hubs, 14g black stainless steel spokes and front 12mm/ rear 12×142 thru-axle with Switch Lever | WTB STX i25 TCS (UST Tubeless Compliant System) disc rims, 32H, Formula alloy 6-bolt sealed bearing rear hub, 14g black stainless steel spokes and front 12mm/ rear 12×142 thru-axle with Switch Lever |
| Tires | WTB Byway Tire with DNA compound, 650 x 47c | WTB Byway Tire with DNA compound, 650 x 47c |
| Derailleurs | Shimano Deore RD-M4120 GS Shadow Plus rear | Shimano Altus RD-M2000 SGS Shadow or microShift RD-M46L long cage rear |
| Shift levers | Shimano Deore RapidFire Plus SL-M4100, 10-speed | Shimano Altus RapidFire Plus SL-M2010 or microShift SL-M859, 9-speed |
| Chain | KMC X10 | KMC Z9 |
| Cassette | Shimano CS-M4100, 10-speed, 11-42T | Shimano CS-HG201, 9-speed, 11-36T |
| Crankset | FSA Vero Pro crank, 40T MegaTooth, 15/17” 165 19/21” 170. 23” 175mm | FSA Tempo crank, 42T, 15/17” 165 19/21” 170. 23” 175mm |
| BB Set | FSA sealed cartridge, 68 x 110.5mm | FSA sealed cartridge, 68 x 110.5mm |
| Pedals | Platform style, alloy | Platform style, alloy |
| Brakeset | Tektro HD-M280/281 hydraulic Flat Mount disc brakes with 160mm rotors and Tektro brake levers. 15-17” M281 (83mm reach); 19-23” M280 (88mm reach) | Tektro HD-M280/281 hydraulic Flat Mount disc brakes with 160mm rotors and Tektro brake levers. 15-17” M281 (83mm reach); 19-23” M280 (88mm reach) |
| Handlebar | Jamis Riser bar, aluminum, 10 ̊ sweep, 3ç up sweep, 20mm rise, 31.8 x 680mm (15/17/19”) 700mm (21/23”) | Jamis Riser bar, aluminum, 10 ̊ sweep, 3ç up sweep, 20mm rise, 31.8 x 680mm (15/17/19”) 700mm (21/23”) |
| Stem | Jamis, 3D forged alloy, 3 ̊ rise, Length-40mm (15/17”), 50mm (19/21”), 60mm (23”) | Jamis, 3D forged alloy, 3 ̊ rise, Length-40mm (15/17”), 50mm (19/21”), 60mm (23”) |
| Grips | MTB Kraton/Gel Double Density Grip Lock-on | MTB Kraton/Gel Double Density Grip 125mm |
| Seat Post | Jamis alloy micro-adjust, 27.2 x 350mm alloy clamp with QR seatpin | Jamis alloy micro-adjust, 27.2 x 350mm alloy clamp with QR seatpin |
| Saddle | Selle Royal Vivo ERGO | NEW Jamis Sport with SL top |
| Sizes | 15”, 17”, 19”, 21”, 23” | 15”, 17”, 19”, 21”, 23” |
| Color | Riptide | Gloss Black |
| Weight | 28.0 lbs | 28.0 lbs |
| MODEL | SIZE | TT EFFECTIVE | HT ANGLE | ST ANGLE | CHAINSTAY | WHEELBASE | FORK RAKE | BB DROP | HEADTUBE | STANDOVER | STACK | REACH |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S2, S3 | 15 | 21.65 / 550 | 71° | 74.5° | 17.13 / 435 | 41.22 / 1047 | 2.09 / 53 | 2.76 / 70 | 3.54 / 90 | 27.80 / 706 | 20.91 / 531 | 15.87 / 403 |
| S2, S3 | 17 | 22.95 / 583 | 71° | 74.5° | 17 / 440 | 42.76 / 1086 | 2.09 / 53 | 2.76 / 70 | 4.72 / 120 | 29.13 / 740 | 22.01 / 559 | 16.85 / 428 |
| S2, S3 | 19 | 23.62 / 600 | 71.5° | 73° | 17.52 / 445 | 42.83 / 1088 | 1.97 / 50 | 2.56 / 65 | 5.91 / 150 | 30.59 / 777 | 23.07 / 586 | 16.57 / 421 |
| S2, S3 | 21 | 24.21 / 615 | 71.5° | 73° | 17.72 / 450 | 43.66 / 1109 | 1.97 / 50 | 2.56 / 65 | 7.09 / 180 | 31.97 / 812 | 24.17 / 614 | 16.81 / 427 |
| S2, S3 | 23 | 25.31 / 643 | 71.5° | 73° | 17.72 / 450 | 44.88 / 1140 | 1.97 / 50 | 2.36 / 60 | 8.27 / 210 | 33.43 / 849 | 25.12 / 638 | 17.64 / 448 |
